POE 8xPOE 2xUplink switch dedicated to IP monitoring. The switch allows up to 300 m of data transmission and power range for monitoring systems. No configuration required. The device is ideal for small and medium-sized monitoring systems. The automatic features of this switch make installation and operation easy and hassle-free.
- Ports: 8 pcs of 10/100/1000Mbps RJ45 PoE ports + 2 pcs RJ45 uplink ports with automatic link speed detection
- Auto MDI / MDIX patching
- Standard protocol: IEEE 802.3 10BASE-T, IEEE 802.3u 100Base-TX, IEEE 802.3x, IEEE802.3i 10Base-T
- Port 1-8 support standard IEEE 802.3af/at
- Type of transmission: Store and Forward
- Bandwidth: 20 Gbps
- Forwarding speed: 14.88 Mpps
- Buffer memory: 1.25 M
- MAC address table: 4 K
- Data flow control
- Support MAC self learning and updating
- POE and network LED indicator
- Twisted pair transmission:
- 10BASE-T: Cat5 UTP (≤300 m)
- 100BASE-TX: Cat5 or later UTP (≤100 m)
- Built in switch (no need to restart power supply):
- Extend: AI extend 300 m transmission
- VLan: Turn on, 1-4 Port support each port Isolation & VLAN
- Support Watchdog function by default: 1-4 Port suport AI-PoE Network self-healing
- Max/Average power per port: 30 W / 15.4 W
- Total power: 120 W
- Power supply PIN: 1/2(+), 3/6(-)
- Power consumption:
- standby: <4 W
- full load: 120 W
- Built in power adaptor 220-240 V / 50 Hz
- Operating temperature:-20℃~55℃
- Storage temperature: -40℃~75℃
- Operating air humidity: 5% ~ 90%, non-condensing
- Storage humidity: 5% ~ 95%, non-condensing
- Dimensions: 195 x 135 x 40 [mm]
