SQB-Saddle 614 Ergowave active 2.1 S-Tube 15 cm

The gravel bike is the swiss knife of the bicycle industry: whether on- or off-road, it is the perfect companion for anyone who prefers a bit more comfort. Matching these characteristics, the 614 ERGOWAVE® active 2.1 is the gravel saddle from SQlab. This model combines the advantages of the well-known 611 ERGOWAVE® saddles (MTB) and 612 (Road): a waisted shape offers maximum legroom off-road, at the same time saddle has the thicker padding of the 611 ERGOWAVE® model to provide maximum cushioning and comfort on rough off-road trails. The SQlab active technology offers additional comfort, especially on the gravel bike, by mobilizing the intervertebral discs. Additionally, a premium quality Kevlar material protects the saddle in its exposed areas.

ERGOWAVE® shape
The wave-like shape and raised rear section provides perfect rearward support and an optimal pressure distribution which reaches deep into the bodily structures, resulting in improved power transmission. The lowered nose in combination with the dip provides an optimal pressure relief for the perineal area.

active-Technology
Especially on the gravel bike, the SQlab active technology offers additional comfort on long distances. The active technology allows the saddle to follow the pedaling movement, which increases comfort, mobilizes the intervertebral discs and minimizes the pressure on the sit bones. The SQlab active technology is adjustable via elastomers in three degrees of hardness.

Specifications

• AREA OF USE/BICYCLE TYPE Gravel
• WEIGHT(S) IN G approx. 229 / 231 / 234 / 244 / 254
• ACTIVE TECHNOLOGY Yes - Sport
• MOUNTING HEIGHT IN MM approx. 45
• SIZE(S) IN CM (EFFECTIVE SADDLE WIDTH) 12 / 13 / 14 / 15 / 16
• LENGTH IN MM approx. 275
• MATERIAL RAILS S-Tube (light metal alloy - hollow)
• MATERIAL BASE Glass Fibre reinforced Polyamide Compound (PA12 + GF)
• MATERIAL PADDING Superlight Foam
• MATERIAL COVER Microfibre
• HARDNESS IN SQ-SHORE 55
• RELIEF OF PERINEAL AREA IN % 65
• MAXIMUM LOAD IN KG 100
• MAXIMUM TORQUE IN NM 18
• E-BIKE READY Yes
• DIN/ASTM CATEGORIES 4
• GENDER Unisex
