MEDICLINICS M23A U-Flow hand dryer, White

• U-flow automatic hand dryer with ABS cover, white finish.

• Its innovative and ergonomic U-shaped design allows total freedom of movement, making hand drying a unique experience full of protection and hygiene.

• The U-Flow is a “hands through”, fast, energy efficient, environmentally friendly, hygienic & stylish hand dryer, suitable for high traffic facilities.

• It has one pair of IR sensors on both sides of the “U” opening for instant hand detection.

• It incorporates a quick assembly / disassembly kit for the machine ( plug-in system) that allows you to install and uninstall the hand dryer easily, quickly and safely, making maintenance much more efficient and reducing your costs at the same time.

• It incorporates a HEPA media filter that filters suspended solid particles (pollen, dust mites, tobacco smoke, etc. ) significantly improving air quality.

• It is delivered with an ionizer ("Ion Hygienic" technology) that purifies the air through negatively charged particles (anions), eliminating many of the particles and germs carried by the air, making it healthier and pure. These ions inhibit the reproduction of micro-organisms in the product throughout its lifetime.

• Biocote® antimicrobial and antibacterial protection based on silver ion technology. BioCote Antimicrobial Technology reduces the growth of microbes such as bacteria and mould by up to 99.9%.

• Maximum air speed 350 km/h.

• Dries hands in only 8 / 10 seconds.

• Adjustable motor power, allowing electricity consumption to be regulated between 420 and 1100W.

• 30 seconds safety timer.

• Lowest noise level in its category. (72.5 dBA in Eco mode).

• Prevents water on the floor: It has two removable water tanks and can be connected directly to the toilet drain to remove waste water.

• It has odour neutralizing beads to create a clean and pleasant atmosphere in the bathroom. (Ref. RCFB001).

Documents :

Data Sheet

CAD Drawing

Dimensions

Installation Manual

High Resolution Picture
